ARM080.705
Steel Wall Mounted
Module - With Bellow
The Steel Wall-Mounted Module - With Bellows helps fixing the operator arms horizontally which are positioned on vertical surfaces. This product with its cast steel body gives reliability for heavy loads and long-distance arm configurations. It allows a mobility of 90° to the right and left.
| Weight | 3330gr. |
| Color | RAL 7035 / Bellow RAL 7016 |
| Amount in package | 1 |
| Package Dimensions | 2185x155x135 mm |
| Material | Steel Casting |
| Movement | Right 90°, Left 90° |
